High Safety Factory Roller Shutters
Design

        Extra size of roller shutters that required high technical skill of welding thick steel. Moreover, in order to make perfect level of installation that would create the minimal depreciation, the installation team required to have high experience and skill. V.C.Autoshutters.co, LTD has been in the roller shutters industry for more than 30 years, thus you can be sure that our heavy-duty roller shutters come with great safety and high quality.

Security Material

        Shutter lines are produced from zinc steel with the thickness of 0.42mm-1.6mm. It is able to use as shop houses doors, factory doors, and large manufacture doors.

Color & Specification

  • Large Single curve (Gray)

    #20 หนา 0.90mm
    #19 หนา 1.00mm
    #18 หนา 1.20mm

  • Large Single curve (Cream)

    #20 หนา 0.90mm
    #19 หนา 1.00mm
    #18 หนา 1.20mm

Special Feature

        The size of Heavy-duty roller shutter is maximal at the width of 20meters, without separation in the middle. This is to create larger usage area with the optimal safety.

The device specification
Width not exceeding 5-8 meters
  • Panel: Large Single curve thickness 0.8mm
  • Bottom:2" steel angle.
  • Rail: Zinc steel rail size 7 cm.
  • Frame: Flat steel plate.
  • Axle: Axle Ø 6"
  • Motor: ShutteX CM2-900 7rpm with Safety Lock, Safety Switch and Flexible Joint
Width not exceeding 8-10 meters
  • Panel: Large Single curve thickness 1.0mm
  • Bottom:2" steel angle.
  • Rail: Zinc steel rail size 7 cm.
  • Frame: Flat steel plate.
  • Axle: Axle Ø 8"
  • Motor: ShutteX CM3-1500 5.2rpm with Safety Lock, Safety Switch and Flexible Joint
Width not exceeding 10-12 meters
  • Panel: Large Single curve thickness 1.2mm
  • Bottom:2" steel angle.
  • Rail: Zinc steel rail size 10 cm.
  • Frame: Flat steel plate.
  • Axle: Axle Ø 10"
  • Motor: ShutteX CM3-2000 3.6rpm with Double Chain, Safety Lock, Safety Switch and Flexible Joint
Device for accident prevention

  • Lighting Indicator

    To the staff of the department. Observe the operating status clearly.

  • Safety Switch

    Prevent user carelessness effectively.

  • Master Limit

    Prevent the error of Limit. The system will stop the power supply immediately.

  • Heavy Duty Contraption

    Heavy Duty equipment such as ball bearings, sprockets and platens. To support hard work and more life. Reduce the rate of deterioration of the device. Reduce the cost of maintenance or repair costs.
